Trinocular Observation Head
- Sidentopf observation head inclined at 30° rotatable at 360
- Vertical focusable phototube for micro photography.
- Diopter adjustment ring on ocular tube(±5).
- Interpupilary distance from 50mm to 75mm..
Eyepiece(anti fungal treated)
- Extra wide field 10x(paired)
F.O.V.22mm Ocular dia 30mm.
- Objective(infinity corrected & anti fungal treated)
- LWD Plan Achromatic Metallurgical Objective 5x
- LWD Plan Achromatic Metallurgical Objective 10x
- LWD Plan Achromatic Metallurgical Objective 20x
- LWD Plan Achromatic Metallurgical Objective 50x(S.L.)
- LWD Plan Achromatic Metallurgical Objective 100x (Dry)
Mechanical Body
- Co-axial focusing control with large knob.
- PRE-FOCUSING LEVER & TENSION ADJUSTMENT RING.
- Reverse angle quintuple nosepiece revolving on Ball bearing with slot for polarizer & DIC attachments.
- Rotatable & rackless motorized mechanical stage size 150mm x 150mm.
- Low positioned co-axial controls on ball bearing guide ways.
- XY sample stage Motorized
- XY stagetravel 100mm x 100mm
- Z focusing stage Motorized with autofocusing algorithm
- Z focusing stage travel = 25mm
Reflected Illumination
- 5W LED, Warm color, Koehiers with illumination with oblique device, center adjustable field and aperture diphagram
Standard Accessories
- 5W LED bulb, dust cover, blue filter, guarantee card operating manual and Styrofoam molded pack
Sub Stage Condenser
- Swing out front lens, abbe condenser N.A. 0.9, filter holder and ilris diaphragm
